The industrial takeoff platform
Industrial takeoff - every trade, done in hours.
theTakeoff.ai reads your drawings - P&IDs, isometrics, structural, mechanical and more - and returns bid-ready takeoffs across the disciplines in an industrial bid. Piping is live today; the platform is expanding one trade at a time.
Built with estimators across process, plant and industrial contractors
Every count traced back to the sheet it came from
Pick a discipline, then click any item in the list — the drawing zooms to the exact spot it was read from, with the spec, the evidence and what is still missing before it can be priced.
BJD4"✓✕
Symbol key read off this sheet
BJD / BJDF
ball valve
OJD (LO)
gate valve, locked open
NSD
needle valve, 1/2in bleed
BSDF (LO)
check valve on relief
CSD
globe valve — not in legend
P&ID takeoff
13 components found on this sheet · 4 need a legend or spec sheet before pricing
Sheet 1All sheets (2)
BALL VALVE2 items
3ball valve· 4"✓✕
ball valve · 4"u003
Resolved from legend
What this is
What it is
The kicker valve. Opened to divert main-line flow in behind a loaded pig and push it out of the barrel; shut in normal operation so product runs straight down the main line. Identified as BALL VALVE from the legend — bowtie with an open circle at the centre crossed by an X; the drawing labels it BJD.
What it does
kicker line block. open ball in bowtie on the 4in kicker run into the barrel; label 4in BJD
Name taken from
agent
Pipe it sits on
Bore
4"
Specification
Code on sheet
BJD
Spec class
unresolved — 0 possible
Rating
ANSI Class 600
End connection
RTJ flanged
Resolved by
11712001-20810-00301 rev A, item 4
Evidence
Fire safe to API RP 6F / 6FA / 607; painted to COMPANY protective coating spec; stainless steel tag stating make, model, tag no., MAWP/temp and GI-37R.
Drawing attributes
Size
4"
Spec
BJD
Symbol
ball valve
This part of the system
This assembly
600# carbon steel body, RTJ flanged ends, regular port, lever operated, chrome or ENP plated stem and ball, trunnion mounted ball, Teflon seats.
What it takes to build
Fire safe to API RP 6F / 6FA / 607; painted to COMPANY protective coating spec; stainless steel tag stating make, model, tag no., MAWP/temp and GI-37R.
Evidence
ID
u003
12ball valve· 2"✓✕
GATE VALVE1 item
2gate valve· 2"✓✕
NEEDLE VALVE1 item
1needle valve· 1/2"✓✕
CHECK VALVE1 item
4check valve· 1"✓✕
GLOBE VALVE1 item
5globe valve· 1"✓✕
RELIEF VALVE1 item
6pressure safety valve· 1"x1"✓✕
INSTRUMENT1 item
7pressure indicator· 1/2"✓✕
INSTRUMENT TAP ASSEMBLY1 item
31instrument tap assembly· 2"x1/2"✓✕
CLOSURE1 item
10quick-opening closure· 12"✓✕
FITTING1 item
11concentric reducer· 12"x10"✓✕
TIE IN POINT2 items
34tie in point· 10"✓✕
35tie in point· 2"✓✕
How it works
Price Your Bid 70% Faster with theTakeoff.AI
See it on your drawings1
Material Take-Off
Upload your drawing set and theTakeoff.ai extracts every length, fitting, weld and hardware item into a structured MTO across disciplines.
Deviation Detection
The platform flags mismatches, missing items and spec conflicts between drawings and notifies you before they reach the bid.
Material and Labor Pricing
Apply your price books and labor rates directly to the MTO, so you go from quantities to a priced estimate without switching tools.
The outcome
The math is the pitch.
Turn a heavy industrial take-off from weeks into hours, save estimator time on every bid, and put that capacity toward the work you're currently turning down.
WeeksHours
Per industrial take-off
~65%
Estimator time claimed
+ bids
Capacity - more wins
Industrial estimates per year40
23,000
Hours reclaimed / yr
$2.24M
Estimator cost saved / yr
Proof
Proof you can check line by line.
No borrowed logos. Every claim here is grounded in a code you already estimate under - and checkable inside the product.
02 / VOLUMEField-tested
400+
projects tested
Across 20,000+ drawings - spec breaks, revisions, and messy scans included.
03 / CODENative
B31.3&B16.5
ASME, native
Ratings and dimensions live in the engine - not a lookup table you maintain by hand.
Your bid data stays private.
TheTakeoff AI is built for sensitive bid packages, with access controls, encryption, and audit trails so your team can work fast and securely.
FAQs
Questions, answered.
The short answers estimators want before sending their first live package.
P&ID takeoff is the process of reading a set of Piping and Instrumentation Diagrams and counting everything in scope - every valve, instrument, equipment item, in-line specialty and line - then decoding each line number into its pipe class so a contractor can size and price a bid. It is the first quantity takeoff in any process-piping estimate.
A dense P&ID takes a senior estimator 30 to 60 minutes to take off by hand. A typical process-unit bid package contains 300 or more P&IDs, so manual takeoff consumes 250-plus estimator-hours per bid - the single biggest constraint on how many tenders a team can chase.
theTakeoff.ai extracts every valve, instrument, equipment item and in-line specialty on the sheet, reads and decodes every line number into size, pipe class, service and insulation, factors bulk pipe and fitting quantities, and flags tie-ins, spec breaks and battery limits - then exports a complete, priced scope takeoff to Excel.
Yes. theTakeoff.ai processes scanned, photographed and older, legacy P&IDs - including drawings from the 1980s and 1990s - alongside native CAD exports. Low-confidence detections are flagged for estimator review rather than guessed.
theTakeoff.ai detects and classifies components at high first-pass accuracy and improves on every bid as it learns a client's drawing conventions and symbol libraries. Every detection is shown beside the source drawing for accept, edit or reject, so the estimator signs off on the final count.
No. theTakeoff.ai automates the reading - opening every sheet, counting every component, decoding every line. The estimator keeps the judgment: interpreting scope, identifying spec breaks, assessing how it gets built and the commercial risk, and signing off on every quantity.
